3w and 4w applications

eDrive

Patented Axial Flux Technology

Combines patented, cutting edge axial flux technology with an integrated controller & transmission offering a class leading 3-in-1 eDrive solution.

Provides high torque & power density enabling impressive performance in a lightweight & compact package with simple vehicle integration.

Motor & Controller Performance Boost (S2 - 10s) Peak (S2 - 2min) Continuous (S1 - 30min+)
Phase current (Arms) 600 450 280
Torque (Nm) 135 105 65
Torque knee point (rpm) 1300 1500 1600
Power (kW) 21 19 12
Motor, Controller & Transmission Overview (eDrive)
Model AFT140i-48V eDrive
Transmission type Single Speed Offset
Dry mass 42kg
Transmission differential Included
Transmission stock gear ratios 5.27:1, 6.36:1, 8.98:1 and 11.39:1
Transmission custom gear ratio range 3.69:1 to 11.39:1
Transmission configuration options eDrive or eAxle

Patented Axial Flux Technology

Combines patented, cutting edge axial flux technology with an integrated controller & transmission offering a class leading 3-in-1 eDrive solution.

Provides high torque & power density enabling impressive performance in a lightweight & compact package with simple vehicle integration.

Motor & Controller Performance Boost (S2 - 10s) Peak (S2 - 2min) Continuous (S1 - 30min+)
Phase current (Arms) 600 450 280
Torque (Nm) 135 105 65
Torque knee point (rpm) 2600 2900 3000
Power (kW) 45 43 21
Motor, Controller & Transmission Overview (eDrive)
Model AFT140i-96V eDrive
Transmission type Single Speed Offset
Dry mass 42kg
Transmission differential Included
Transmission stock gear ratios 5.27:1, 6.36:1, 8.98:1 and 11.39:1
Transmission custom gear ratio range 3.69:1 to 11.39:1
Transmission configuration options eDrive or eAxle

Relevant applications

3 & 4 Wheel
